SI1142-A11-GMR
SI1142-A11-GMR microchip DIP
PROXIMITY/AMBIENT LIGHT SENSOR IC WITH I 2C INTERFACE
Delivery
EXW
minimum order
10 pieces
Supply Ability
4200pieces / Day
Country of Origin
PHI
Stock Time
1-2Day
Quantity
SI1142-A11-GMR
PROXIMITY/AMBIENT LIGHT SENSOR IC WITH I 2C INTERFACE
Integrated infrared proximity detector
Proximity detection adjustable from
under 1 cm up to 200 cm
Three independent LED drivers
15 current settings from 5.6 mA to
360 mA for each LED driver
25.6 μs LED driver pulse width
50 cm proximity range with single
pulse (<3 klx)
15 cm proximity range with single
pulse (>3 klx)
Operates at up to 128 klx (directsunlight)
High reflectance sensitivity< 1 μW/cm2
High EMI immunity without shielded
packaging
Integrated ambient light sensor
100 mlx resolution possible,
allowing operation under dark glass
1 to 128 klx dynamic range possible
across two ADC range settings
Accurate lux measurements with IR
correction algorithm
Industry's lowest power consumption
1.71 to 3.6 V supply voltage
9 μA average current (LED pulsed
25.6 μs every 800 ms at 180 mA
plus 3 μA Si114x supply)
< 500 nA standby current
25.6 μs LED “on” time keeps total
power consumption duty cycle low
without compromising performance
or noise immunity
Internal and external wake support
Built-in voltage supply monitor and
power-on reset controller
Serial communications
Up to 3.4 Mbps data rate
Slave mode hardware address
decoding (0x5A)
Small-outline 10-lead 2x2 mm QFN
Temperature Range
–40 to +85 °C
programming chip
memory chip ic
Electronic components are the basic building blocks of electronic circuits and are used to construct
various circuits that enable electronic products to perform various functions. The following are common
electronic components and their main functions:
1. Capacitor: used for storing charge, smoothing voltage, filtering, delaying, etc.
2. Resistor: used for limiting current, changing voltage, dividing voltage, regulating current, etc.
3. Diode: used for rectification, voltage stabilization, switching, etc.
4. Transistors such as thyristors and triodes: used for signal amplification, current control, switching, etc.
5. Integrated circuits (ICs): integrate multiple electronic components to achieve complex circuit functions.
6. Sensors: convert various physical quantities into electrical signals, such as temperature, humidity, light intensity, pressure, etc.
Electronic components are widely used in various electronic products such as computers, mobile phones,
1. Capacitor: used for storing charge, smoothing voltage, filtering, delaying, etc.
2. Resistor: used for limiting current, changing voltage, dividing voltage, regulating current, etc.
3. Diode: used for rectification, voltage stabilization, switching, etc.
4. Transistors such as thyristors and triodes: used for signal amplification, current control, switching, etc.
5. Integrated circuits (ICs): integrate multiple electronic components to achieve complex circuit functions.
6. Sensors: convert various physical quantities into electrical signals, such as temperature, humidity, light intensity, pressure, etc.
Electronic components are widely used in various electronic products such as computers, mobile phones,
televisions, audio, automotive electronics and more. Their function is to transmit, process and convert signals in
the circuit to provide the foundation for electronic products to perform various functions.
